Land Rover Part Number: TGK500010 - Oil Pan Gasket - ZF 6-Speed Automatic Transmission
TGK500010 is an oil pan gasket for ZF 6HP26 and ZF 6HP28 6-speed automatic transmissions. Fitted to the transmission oil pan/sump on vehicles with these transmissions, it seals the joint between the oil pan and the transmission housing to prevent fluid leaks. The gasket should be inspected whenever the transmission oil pan is removed and replaced if damaged or brittle to ensure a reliable seal.
Compatibility
- Discovery 3 (2005-2009) - 6 Speed Auto ZF 6HP26
- Discovery 4 (2010-2016) - 6 Speed Auto ZF 6HP26 / ZF 6HP28
- Range Rover (2002-2009) L322 - 6 Speed Auto ZF 6HP26
- Range Rover (2010-2012) L322 - 6 Speed Auto ZF 6HP28 - From VIN AA000001
- Range Rover Sport (2005-2009) L320 - 6 Speed Auto ZF 6HP26
- Range Rover Sport (2010-2013) L320 - 6 Speed Auto ZF 6HP26 / ZF 6HP28
Frequently Asked Questions
TGK500010 forms the seal between the transmission oil pan (sump) and the ZF 6HP26 / 6HP28 transmission case to prevent automatic transmission fluid leaks. It should be checked for deterioration or damage whenever the pan is removed and replaced if any signs of hardening, tearing or leakage are present.
| Model | Variant |
|---|---|
| Land Rover Discovery 3 (2005-2009) | 6 Speed Auto ZF 6HP26 |
| Land Rover Discovery 4 (2010-2016) | 6 Speed Auto ZF 6HP26 / ZF 6HP28 |
| Land Rover Range Rover (L322) (2002-2009) | 6 Speed Auto ZF 6HP26 |
| Land Rover Range Rover (L322) (2010-2012) | 6 Speed Auto ZF 6HP28 - From VIN AA000001 |
| Land Rover Range Rover Sport (L320) (2005-2009) | 6 Speed Auto ZF 6HP26 |
| Land Rover Range Rover Sport (L320) (2010-2013) | 6 Speed Auto ZF 6HP26 / ZF 6HP28 |
If you are unsure of compatibility with your vehicle, you can also confirm by checking against your V.I.N. Simply reach out to us with your V.I.N and desired part number via our Contact page or use our Finding Part Numbers page.
Replace the gasket whenever the transmission oil pan is removed or if a fluid leak is detected; fitting a new gasket after removing the pan is standard practice to ensure a reliable seal. If unsure, consult the vehicle service manual or a qualified technician.
- C8 products are usually supplied by Britpart.
- L8 products are genuine Land Rover parts.
- Z8 products are normally supplied by Allmakes.
All products and accessories available on LRDirect.com come with a 2-year warranty.
